Ob duobus longa-term cooperante cum Refoxroth ex MCMLXXIX, Huade® 4WE VI series directional spario valvae est parabilis alternative ad Rexroth in eadem exemplar. Est unus de maxime popularibus et late usus directional valvulae. Huaade habet DCCL provectus apparatu importari ab toto orbe terrarum et stricte probatio ratio ut superior perficientur eius hydraulicis valvulae. R & D et productio Management Ratio Meets ISO9001, ISO14001 et ISO45001. Omnes solenoid directional valvulae CE certified. Huadrae® hydraulicis valvulae late in Engineering et constructione machina, metallurgy, machine Tools, environmental praesidium, shipbuilding, aerospace, blasphemant transit, PETROLEUM et PETROCHEMICUS, Military Industry et Alia in Sinis.
|
HYDRAULICUS |
|||
|
Max.opating pressura portus A, B, P (MPa) |
ad 35.0 |
||
|
Portus T (㎫) |
XXI (-); XVI (~) |
||
|
Et symbolis A et B, Portus T debet esse sicut exhauriat portum |
|||
|
Max.flow (l / min) |
LXXX (-); LX (~) |
||
|
Pressura fluidum |
Mineralis oles et phosphate Ester |
||
|
Viscosity range (MM2 / s) |
2.8 ~ D |
||
|
Pressura fluidi temperatus range (℃) |
-30 ~ LXXX + |
||
|
Gradum contaminationem |
Maximum permissible degree of contamination of hydraulic fluid to NAS 1638 class9. |
||
|
Electrical |
|||
|
Voltage Type |
DC |
AC L / 60Hz |
|
|
Praesto voltages (v) |
XII, XXIV, XLII, LX, XCVI |
XLII, CX, CXX, CCXXX |
|
|
CX, CLXXX, CCV, CCXX |
L / 60hz |
||
|
Power consummatio (W) |
30 |
||
|
Habens Power (VA) |
- |
50 |
|
|
Switch-in potestate (VA) |
- |
220 |
|
|
Officium |
continuus |
||
|
Switching ad IS0 (VI) CDIII |
De (MS) |
XXV ad XLV |
X ad XX |
|
Off (MS) |
X ad XXV |
XV ad XL |
|
|
Tutela ad Laudate |
IP LXV |
||
|
Switching Frequency (cycles / h) |
ad (XV) |
ad (VII) CC |
|
|
Cum electrica hospites in tutela conductor (Pe) |
|||
Features:
▶ Direct Solenoid Actuated Directional FUSUS CYMBALONALIS ALBUM ECFECTUS version
▶ infectum ACUS DC vel AC Solenoids cum amovibilibus coil
▶ solenoid coil potest rotentur per XC °
▶ non est necessarium aperire pressura stricta camera quando mutantur in coil
▶ electrica hospites vel singula seu centralis hospites
▶ manus override, libitum
▶ porting exemplar ad Laudate XXIV CCCXL forma A, ISO (IV) CDI et Cetop - RP 121h
Application:
Directional valvulae type 4We VI d sunt solenoid operated directional spolia valvulae. Et control initio, subsisto et directionem fluidum.
Per se directional imperium valvulae consistit de habitationi (I), unus vel duo solenoids (II), in potestate Spool (III), et unus vel duo reditus fontium (IV). In de-energizing conditio in potestate FUSUS (III) tenendum in neutrum vel initial situ per reditus fontibus (IV), nisi ad impetum spool (III). Natus esto Pin SELENUS (II). Et vis de Solenoids (II) Acta per plunger (V) in potestate Spool (III) et tendat hoc ex suo neutrum in P ad A et T.
Cum solenoid (II) est de-energizing, in potestate FUSUS (III) est rediit ad suum neutrum situ per reditus fontium (IV).
An libitum manus override (VI), concedit motus de potestate Spool (III) sine energising solenoid.
Structure Diagram nos VI 61b
