Strategic cooperante inter Chinese et Germanico imperia ex MCMLXXIX, Haade habet incorporatus secans-ore technology a reboth. Huade® sumus IV directional sparica valvae est parabilis alternative ad idem exemplar obtulerunt a Regrot. HAUDAE Ponit magna accentus in qualis. Huade habet stricte probatio ratio ut omnis directional valvae habet superior perficientur. Et solenoid valvae series transiret CE Certification. Huade® hydraulicis valvulae late in Engineering et constructione machinatione, metallurgy, machina instrumenta, environmental tutela, shipbuilding, aerospace, blasphemant transit, PETROLEUM et PETROCHEMICA, Military Industry et aliis agris. Est certa nationalis notam in Sinis.
|
Data Hydraulica Technical |
||
|
Max.opating pressura-portubus A, B, P (㎫) |
ad 21.0 |
|
|
Portus T (㎫) |
10.0 .with symbolis A vel B Portus T oportet utendum quod Leakage Portus |
|
|
Max.flow (l / min) |
ad XXV |
|
|
Pressura fluidum |
Mineralis oleum et phosphate Ester |
|
|
Viscosity range (MM2 / s) |
2.8 ad D |
|
|
Pressura fluidi temperatus range (℃) |
-30 ~ LXXX + |
|
|
Gradum contaminationem (㎛) |
Maximam permissibilis gradum contagione Hydraulicorum fluidi ad Nas MDCXXXVIII genus IX. Nos igitur suadeo filter cum minimum retention rate of Β≥ LXXV |
|
|
Pondus (kg) |
Valvae cum I solenoid 0.9 |
|
|
Electrical Technical Data |
||
|
Praesto voltages (v) |
XII. 24.220.110R 220r |
|
|
Power consummatio (W) |
22 |
|
|
Officium |
continuus |
|
|
Switching Tempus |
De (MS) |
XX ad XXX |
|
Off (MS) |
X ad XX |
|
|
Max. Ambientium temperatus (℃) |
CAP |
|
|
Max. Coil temperatus (℃) |
XV |
|
|
Donec ad Laudate XL L |
Ip65 |
|
|
Switching Frequency (cycles / h) |
15000 |
|
|
Cum electrica connexionem in tutela Conductor (PE) debet esse coniuncta secundum pertinet lege |
||
Features:
▶ Directional valvulae type nos IV sunt solenoid operated directional spolia valvulae
▶ infectum pin Solenoids de recta vel alterna current
▶ Portus exemplar ad ISO (IV) CDI et Cetop - RP 121h
Application:
Directional valvulae typus nos IV sunt solenoid operated directional spolia valvulae. Et control initio, subsisto et directionem fluidum.
Haec directional valvulae basically consistere de habitationi (I), unus vel duo solenoids (II), in potestate Spool (III) et unus vel duo reditus fontes (IV).
In potestate Spool (III) tenuit a reditu Spring (IV) in centralis vel in initial situ (nisi dideded spolia). Imperium FUSUS (III) est actum per infectum pin Solenoids (II). In energized. Et vis solenoid (II) agit per plunger (V) in potestate Spool (III) et vices eadem ex eius requiem situ ad desideravit finem positus. Ut, quod requiritur fluxus exemplum a P ad A et B ad TO P ad B et ad T delectus. Cum solenoid (II) est de-energizing, in potestate Spool (III) est rediit ad suum neutrum
Hoc version est directional valvae cum II switching positiones et positus per reditus Spring (IV). A operuit manual override est provisum est ut imperium FUSUS (III) potest esse operated sine
energising solenoid.
Cutaway View 4We 4-10B
Cartridge IUGULUS
